Features
- Inner ring is the same high strength Ultralight™ 7075 T-6 aluminum used for the standard Renthal sprocket
- Outer ring is electro-less nickel coated steel for ultimate durability and is designed with the minimum amount of material to keep weight down
- The outer ring is expanded at 200°C and then fitted over the inner; this interference fit combined with the wave pattern ensures a permanent bond for the life of the chainwheel
- The flat socket head screws add additional strength to the chainwheel during side impacts and eliminates contact with the chain guide
- Self cleaning mud grooves between each tooth prevent dirt build upand reduce chainwheel wear and weight
- Will outlast a standard all aluminum sprocket by 3 times, yet is much lighter than an all steel rear sprocket
Specs
| Product Name | Sprocket |
| Type | Drive |
| Model | Twinring |
| Color/Finish | Black |
| Material | 7075-T6 Aluminum |
| Tooth Count | 51 |
| Chain Size | 520 |
| Mounting Position | Rear |
| Units | Each |
| Riding Style | Adventure Touring / Dual-Sport / Street / Off-Road |
Fitments
|
|
|
|
Position | Notes |
|---|---|---|---|---|
| 2023-2024 | Kawasaki | KLX230S | - | - |
| 2023-2024 | Kawasaki | KX450X | - | - |
| 2023, 2025 | Kawasaki | KLX230R S | - | - |
| 2022-2024 | Kawasaki | KLX300SM | - | - |
| 2021-2026 | Kawasaki | KLX300 | - | - |
| 2021-2024 | Kawasaki | KX250X | - | - |
| 2021 | Kawasaki | KX 250XC | - | - |
| 2020-2025 | Kawasaki | KLX230R | - | - |
| 2020-2022 | Kawasaki | KLX230 | - | - |
| 2020-2021 | Kawasaki | KLX230 ABS | - | - |
| 2020 | Kawasaki | KLX250 | - | - |
| 2019-2026 | Kawasaki | KX450 | - | - |
| 2017 | Kawasaki | KLX 450 F | - | - |
| 2015, 2017 | Kawasaki | KLX 450 R | - | - |
| 2008-2014, 2016, 2018-2020 | Kawasaki | KLX450R | - | - |
| 2008, 2011, 2015-2017 | Kawasaki | KLX 250 S | - | - |
| 2008 | Kawasaki | KX 250 | - | - |
| 2006-2020 | Kawasaki | KX450F | - | - |
| 2006-2008 | Kawasaki | KX 125 | - | - |
| 2006-2007, 2009-2010, 2012-2014 | Kawasaki | KLX250S | - | - |
| 2006 | Kawasaki | KDX 220 R | - | - |
| 2004-2020 | Kawasaki | KX250F | - | - |
| 2004-2006 | Suzuki | RMZ250 | - | - |
| 1997-2008, 2020-2021 | Kawasaki | KLX300R | - | - |
| 1997-2006 | Kawasaki | KDX 220 | - | - |
| 1997-2005 | Kawasaki | KDX220R | - | - |
| 1994-1998, 2006-2017 | Kawasaki | KLX 250 | - | - |
| 1994-1996 | Kawasaki | KLX250R | - | - |
| 1993-1996 | Kawasaki | KLX 650 A | - | - |
| 1993-1996 | Kawasaki | KLX650R | - | - |
| 1991-1994 | Kawasaki | KDX250 | - | - |
| 1987-2004 | Kawasaki | KX500 | - | - |
| 1985-2007, 2019-2026 | Kawasaki | KX250 | - | - |
| 1985-2005 | Kawasaki | KX125 | - | - |
| 1984-2006 | Kawasaki | KDX200 |
