Features
- S&S cams are tested on the dyno, street and racetrack before being offered to the public
- With hundreds of test hours on them, you know that you are getting the best cam S&S can produce
- Recommend solid or performance aftermarket hydraulic lifters, stock hydraulic tappets are not recommended
- Not recommended for stock displacement or lower compression engines
- For 88" to 103" engines between 9:1 to 10:1 compression ratio
- Best response from 3500 to 6000 rpm
- Spring spacing required
- Made in the USA
- Installer must check coil bind, valve-to-valve clearance, valve-to-piston clearance and cam lobe to case clearance.
Specs
| Product Name | Camshaft |
| Application | Intake / Exhaust |
| Grind | 560S |
| Intake Lift | 0.560" |
| Intake Open | 20° |
| Intake Close | 55° |
| Intake Duration | 255° |
| Intake Lift at TDC | 0.168" |
| Exhaust Lift | 0.560" |
| Exhaust Open | 60° |
| Exhaust Close | 20° |
| Exhaust Duration | 260° |
| Exhaust Lift at TDC | 0.164" |
| Units | Each |
| Riding Style | Street |
Fitments
|
|
|
|
Position | Notes |
|---|---|---|---|---|
| 1984 | Harley-Davidson | FLHX Electra Glide Special | - | - |
| 1983-1984 | Harley-Davidson | FXSB Low Rider - Belt | - | - |
| 1983 | Harley-Davidson | FLHTC Electra Glide Classic | - | - |
| 1983 | Harley-Davidson | FXDG Disc Glide | - | - |
| 1983 | Harley-Davidson | FXRT Sport Glide | - | - |
| 1983 | Harley-Davidson | Electra Glide Standard FLHT | - | - |
| 1982-1983 | Harley-Davidson | FXR Super Glide II | - | - |
| 1982-1983 | Harley-Davidson | Super Glide II FXRS | - | - |
| 1981-1983 | Harley-Davidson | FLTC Tour Glide Classic | - | - |
| 1981-1982 | Harley-Davidson | Electra Glide Classic FLH | - | - |
| 1981 | Harley-Davidson | FXEF Fat Bob | - | - |
| 1981 | Harley-Davidson | Electra Glide Heritage FLH | - | - |
| 1980-1984 | Harley-Davidson | FXWG Wide Glide | - | - |
| 1980-1983 | Harley-Davidson | FLT Tour Glide | - | - |
| 1980-1982 | Harley-Davidson | FLHS Electra Glide Sport | - | - |
| 1980-1982 | Harley-Davidson | FXB Sturgis | - | - |
| 1980 | Harley-Davidson | Tour Glide Classic FLTC | - | - |
| 1979-1980 | Harley-Davidson | Fat Bob FXEF | - | - |
| 1979-1980 | Harley-Davidson | 1200 Fat Bob FXEF | - | - |
| 1979-1980 | Harley-Davidson | 1200 Super Glide FXE | - | - |
| 1979-1980 | Harley-Davidson | Super Glide 80 FXE | - | - |
| 1979 | Harley-Davidson | Low Rider FXS | - | - |
| 1979 | Harley-Davidson | Electra Glide FLH | - | - |
| 1979 | Harley-Davidson | 1200 Low Rider FXS | - | - |
| 1978-1980 | Harley-Davidson | 1200 Electra Glide FLH | - | - |
| 1978, 1981-1984 | Harley-Davidson | FXE Super Glide | - | - |
| 1978, 1980-1982 | Harley-Davidson | FXS Low Rider | - | - |
| 1978 | Harley-Davidson | FX Super Glide | - | - |
| 1977-1981 | Harley-Davidson | Electra Glide FL
|
- | - |
| 1977-1978, 1980-1984 | Harley-Davidson | FLH Electra Glide
|
