Features
- S&S cams are tested on the dyno, street and racetrack before being offered to the public
- With hundreds of test hours on them, you know that you are getting the best cam S&S can produce
- For 84" to 93" motors, not more than 9:1
- Best response occurs in the mid range from 2500 to 5000 rpm
- Recommend high-performance hydraulic or solid lifters
- Made in the USA
- Spring spacing is required.
- Installer must check coil bind, valve-to-valve clearance, valve-to-piston clearance and cam lobe to case clearance.
Specs
| Product Name | Cam |
| Application | Intake / Exhaust |
| Grind | 514 Series |
| Intake Lift | 0.540" Panhead, 0.514" Shovelhead |
| Intake Open | 23° |
| Intake Close | 43° |
| Intake Duration | 246° |
| Intake Lift at TDC | 0.177" Panhead, 0.169" Shovelhead |
| Exhaust Lift | 0.540" Panhead, 0.514" Shovelhead |
| Exhaust Open | 43° |
| Exhaust Close | 23° |
| Exhaust Duration | 246° |
| Exhaust Lift at TDC | 0.177" Panhead, 0.169" Shovelhead |
| Units | Each |
| Riding Style | Street |
Fitments
|
|
|
|
Position | Notes |
|---|---|---|---|---|
| 1984 | Harley-Davidson | FLHX Electra Glide Special | - | - |
| 1983-1984 | Harley-Davidson | FXSB Low Rider - Belt | - | - |
| 1983 | Harley-Davidson | FXDG Disc Glide | - | - |
| 1983 | Harley-Davidson | FXRT Sport Glide | - | - |
| 1983 | Harley-Davidson | FLHTC Electra Glide Classic | - | - |
| 1983 | Harley-Davidson | Electra Glide Standard FLHT | - | - |
| 1982-1983 | Harley-Davidson | Super Glide II FXRS | - | - |
| 1982-1983 | Harley-Davidson | FXR Super Glide II | - | - |
| 1981-1983 | Harley-Davidson | FLTC Tour Glide Classic | - | - |
| 1981-1982 | Harley-Davidson | Electra Glide Classic FLH | - | - |
| 1981 | Harley-Davidson | FXEF Fat Bob | - | - |
| 1981 | Harley-Davidson | Electra Glide Heritage FLH | - | - |
| 1980-1984 | Harley-Davidson | FXWG Wide Glide | - | - |
| 1980-1983 | Harley-Davidson | FLT Tour Glide | - | - |
| 1980-1982 | Harley-Davidson | FXB Sturgis | - | - |
| 1980-1982 | Harley-Davidson | FLHS Electra Glide Sport | - | - |
| 1980 | Harley-Davidson | Tour Glide Classic FLTC | - | - |
| 1980 | Harley-Davidson | 1200 Electra Glide FLH | - | - |
| 1979-1980 | Harley-Davidson | Super Glide 80 FXE | - | - |
| 1979-1980 | Harley-Davidson | 1200 Fat Bob FXEF | - | - |
| 1979-1980 | Harley-Davidson | Fat Bob FXEF | - | - |
| 1979-1980 | Harley-Davidson | 1200 Super Glide FXE | - | - |
| 1979 | Harley-Davidson | 1200 Low Rider FXS | - | - |
| 1979 | Harley-Davidson | Low Rider FXS | - | - |
| 1979 | Harley-Davidson | Electra Glide FLH | - | - |
| 1978-1980 | Harley-Davidson | Electra Glide FL | - | - |
| 1978, 1981-1984 | Harley-Davidson | FXE Super Glide | - | - |
| 1978, 1980-1984 | Harley-Davidson | FLH Electra Glide | - | - |
| 1978, 1980-1982 | Harley-Davidson | FXS Low Rider | - | - |
| 1978 | Harley-Davidson | FX Super Glide | - |
